Audi A4 Wheel Bolt Torque: 120 N·m Factory Specification
Audi A4 Wheel Bolt Torque: 120 N·m Factory Specification with year and generation cautions, dry-thread guidance, tightening pattern.
Audi's January 2020 wheel-and-tire workshop table specifies 120 N·m (about 89 lb-ft) for all listed A4 types except the early RS 4 type 8D, which is separately listed at 140 N·m.
The short answer for the most common A4 application is 120 N·m, but wheel torque is a safety specification—not a value to guess from memory. Model year, platform, stud size, factory wheel design, and an aftermarket wheel manufacturer's instructions can change the required value. This guide therefore starts with the verified application table and then explains how to produce an accurate clamping load instead of merely making the wrench click.
Correct torque keeps the wheel seated evenly against the hub. Too little clamping force can let the wheel move and loosen the fasteners. Too much can stretch studs, damage the nut seat, distort a brake rotor, or make roadside removal impossible. Read the scope note, identify the vehicle and wheel, clean the mating surfaces, and use a calibrated torque wrench for the final passes.
Interactive Audi A4 lug-tightening diagram
STAR PATTERN
Branded downloads includedPNG and PDF exports carry the TorqueSheet logo, torquesheet.com, source-page URL, and republishing attribution request. The PDF source link is clickable.
Select each position to follow a five-lug star pattern. Six-lug wheels use the same opposite-side principle; follow the pattern in the exact owner manual.
Audi A4 Lug Nut Torque Spec
| APPLICATION / ITEM | SPECIFICATION | NOTES |
|---|---|---|
| A4 all listed types | 120 N·m | About 89 lb-ft |
| RS 4 type 8D exception | 140 N·m | About 103 lb-ft; separate early application |
| Fastener | Wheel bolt | Correct seat and effective length required |
| Final pattern | Diagonal/crisscross | Check every bolt with torque wrench |
The A4 uses removable wheel bolts, not captive studs with lug nuts. Match thread, effective length and the wheel's seat geometry. Clean the hub and wheel mating faces, start every bolt by hand, snug diagonally while raised, then lower and finish each bolt with a calibrated torque wrench. Never use the 140-N·m Q5 value just because both vehicles wear Audi wheels.
How to read the A4 torque table
Start with model year and platform rather than wheel diameter. Factory 17-, 18-, and 20-inch wheels can share a value when they use the same stud and seat design, while two trucks sold in the same calendar year can differ because one is an outgoing platform. This is a wheel-bolt specification for the original Audi wheel and correct bolt. The historical type-8D RS 4 exception, accessory wheels, changed hardware and a later superseding instruction must be handled by their own documentation.
The figures in this guide assume original-equipment-style fasteners and clean, dry threads unless the cited manufacturer says otherwise. If an aftermarket wheel, spacer, conversion stud, locking nut, or repair kit supplies a different instruction, that component-specific document controls. Record the final value on the work order so the next technician does not have to infer it.
Common mistakes that produce an unsafe wheel installation
The A4 uses removable wheel bolts, not captive studs with lug nuts. Match thread, effective length and the wheel's seat geometry. Clean the hub and wheel mating faces, start every bolt by hand, snug diagonally while raised, then lower and finish each bolt with a calibrated torque wrench. Never use the 140-N·m Q5 value just because both vehicles wear Audi wheels. Treat an unfamiliar nut seat, stud, spacer, or wheel as a reason to stop and identify the hardware before tightening.
- Using a value from a different generation, heavy-duty model, or aftermarket wheel.
- Applying oil or anti-seize to a specification written for dry threads.
- Cross-threading with an impact gun instead of starting every nut by hand.
- Tightening clockwise around the circle instead of using an opposite-side pattern.
- Letting the full vehicle weight trap a wheel that is not yet centered on the hub.
- Skipping the confirmation pass and the post-service recheck.
Audi A4 specifications can change by model year, engine, platform, wheel, and installed component. Confirm the VIN or engine identity, part numbers, fastener condition, and the current manufacturer instructions before service.
Procedures used with this specification
These steps are the same for every vehicle in this family, so they are documented once rather than repeated on each page. The values above remain specific to this Audi A4.
Audi A4 Wheel Bolt Torque: 120 N·m Factory Specification FAQs
What is the audi a4 lug nut torque spec?+
Audi's January 2020 wheel-and-tire workshop table specifies 120 N·m (about 89 lb-ft) for all listed A4 types except the early RS 4 type 8D, which is separately listed at 140 N·m. Use the application table because the broad search phrase can cover more than one platform or model year.
Technical sources
TorqueSheet favors engine- and component-specific manufacturer instructions over unsourced universal values.
1Audi Wheel and Tire General Information — Edition 01.2020Audi workshop reference table specifying 120 N·m for all A4 and A6 types and 140 N·m for all Q5 types, with a torque-wrench check for every bolt.↗
