The 2012 Jeep Wrangler JK uses a five-lug, 5 x 127-mm (5 x 5-in) bolt circle. Its factory service row identifies 1/2-20 wheel studs and 60-degree cone-seat nuts, with a published wheel-nut torque range of 125–180 N·m (92–132 lb-ft).
The 2012 Jeep Wrangler JK uses a five-lug, 5 x 127-mm (5 x 5-in) bolt circle. Its factory service row identifies 1/2-20 wheel studs and 60-degree cone-seat nuts, with a published wheel-nut torque range of 125–180 N·m (92–132 lb-ft).
This page is deliberately scoped to the 2012 U.S.-market Wrangler JK 3.6L. It does not apply the JK pattern, stud thread or torque range to a YJ, TJ, JL, aftermarket axle or wheel conversion.
Interactive 2012 Wrangler JK specification guide
STAR PATTERN
Branded downloads includedPNG and PDF exports carry the TorqueSheet logo, torquesheet.com, source-page URL, and republishing attribution request. The PDF source link is clickable.
Use this visual as an orientation aid. The exact VIN, engine, trim and manufacturer document control the specification.
Jeep Wrangler Bolt Pattern Specifications
| APPLICATION / ITEM | SPECIFICATION | NOTES |
|---|---|---|
| Bolt pattern | 5 x 127 mm | 5 x 5 in; five lugs |
| Wheel-stud thread | 1/2-20 | 2012 JK factory row |
| Lug-nut seat | 60° cone | Match the wheel seat |
| Wheel-nut torque range | 92–132 lb-ft | 125–180 N·m |
Bolt circle alone cannot establish wheel fit. Confirm center-bore engagement, backspacing/offset, brake and steering clearance, load rating and the wheel maker's approved 60-degree seat before mounting. Do not lubricate the stud or cone unless the exact wheel procedure says to revise the dry-thread torque.
What the JK wheel specification tells you
The 2012 JK's five studs lie on a 127-mm circle, usually written 5 x 127 or 5 x 5 in. The service row further identifies 1/2-20 threads and a 60-degree cone nut. Those details matter because a nut with the wrong thread or seat can appear to tighten while failing to clamp the wheel correctly.
Jeep publishes a 125–180-N·m (92–132-lb-ft) range for the covered hardware. Use the exact wheel and owner/service instructions to select the intended value within that factory range, particularly with approved accessory wheels. Start every nut by hand and tighten across the five-lug pattern in stages.
Why a matching bolt circle is not enough
A 5 x 127 wheel can still interfere with the brake caliper, steering linkage or suspension, or place the tire too far inward or outward. Verify center bore, backspacing/offset, width, diameter, load rating, tire envelope and cone-seat compatibility before purchase.
Clean the hub and wheel mounting faces so corrosion cannot hold the wheel off-center. Keep the factory dry threads free of oil and anti-seize unless the exact procedure provides a revised lubricated value. Recheck seating after service as directed for the installed wheel and investigate any looseness rather than repeatedly adding torque.
Application boundaries for 2012 Wrangler JK
This page is deliberately scoped to the 2012 U.S.-market Wrangler JK 3.6L. It does not apply the JK pattern, stud thread or torque range to a YJ, TJ, JL, aftermarket axle or wheel conversion.
Bolt circle alone cannot establish wheel fit. Confirm center-bore engagement, backspacing/offset, brake and steering clearance, load rating and the wheel maker's approved 60-degree seat before mounting. Do not lubricate the stud or cone unless the exact wheel procedure says to revise the dry-thread torque.
Jeep 2012 Wrangler JK specifications can change by model year, engine, platform, wheel, and installed component. Confirm the VIN or engine identity, part numbers, fastener condition, and the current manufacturer instructions before service.
Procedures used with this specification
These steps are the same for every vehicle in this family, so they are documented once rather than repeated on each page. The values above remain specific to this Jeep 2012 Wrangler JK.
2012 Jeep Wrangler JK Bolt Pattern and Wheel Hardware FAQs
What is the bolt pattern on a 2012 Jeep Wrangler JK?+
It is 5 x 127 mm, also written 5 x 5 inches.
What thread and seat does the 2012 JK lug nut use?+
The cited service row specifies 1/2-20 threads and a 60-degree cone seat.
What is the factory lug-nut torque range?+
Jeep lists 125–180 N·m (92–132 lb-ft) for the covered 2012 JK wheel hardware.
Will every 5 x 127 wheel fit a Wrangler JK?+
No. Center bore, offset/backspacing, width, brake clearance, load rating and lug-seat design must also match.
